About the Book

High frequency core loss and magnetization properties of commercial type MN8CX and PC40, high resistivity, MnZn based, power ferrites are presented over the temperature range of -l50 C to 150 C, at selected values of peak flux density (B (sub p)). Most of the data is at 100 kHz, with some data extended to 200 and 300 kHz for the MN8CX. Plots of the specific Core loss against temperature exhibit the minimal characteristic of such ferrites. These plots show that the MN8CX is optimized for minimum loss at about 25 C, whereas the PC40 is optimized at about 80 C. At the points of minimum loss and for the same B (sub p), the MN8CX has roughly half the losses of the PC40 at the lower flux densities. This loss ratio continues down to cryogenic temperatures. However, above about 80 C the losses are practically equal. The lowest 100 kHz loss recorded, 50 mW/cm3 for the MNGCX at a B (sub p) of 0.1T, equals that of a very low loss, Co based, transverse magnetically annealed, amorphous ribbon material. Except possibly at lower B (sub p) or much higher frequencies, these ferrites are not competitive for low losses over a wide temperature range with certain specialty amorphous materials. Permeability is computed from a linear model, plots against temperature are presented and again compared to the specialty amorphous materials. Niedra, Janis M. Glenn Research Center NASA/CR-1999-209302, E-11779, NAS 1.26:209302...


Best Sellers



Product Details
  • ISBN-13: 9781724007452
  • Publisher: Independently Published
  • Publisher Imprint: Independently Published
  • Height: 280 mm
  • No of Pages: 30
  • Spine Width: 2 mm
  • Width: 216 mm
  • ISBN-10: 1724007459
  • Publisher Date: 25 Sep 2018
  • Binding: Paperback
  • Language: English
  • Returnable: N
  • Weight: 95 gr
