About the Book

The System Identification (SysID) Rack is a real-time hardware-in-the-loop data acquisition (DAQ) and control instrument rack that was designed and built to support inlet testing in the NASA Glenn Research Center 10- by 10-Foot Supersonic Wind Tunnel. This instrument rack is used to support experiments on the Combined-Cycle Engine Large-Scale Inlet for Mode Transition Experiment (CCE‒ LIMX). The CCE‒LIMX is a testbed for an integrated dual flow-path inlet configuration with the two flow paths in an over-and-under arrangement such that the high-speed flow path is located below the lowspeed flow path. The CCE‒LIMX includes multiple actuators that are designed to redirect airflow from one flow path to the other; this action is referred to as "inlet mode transition." Multiple phases of experiments have been planned to support research that investigates inlet mode transition: inlet characterization (Phase-1) and system identification (Phase-2). The SysID Rack hardware design met the following requirements to support Phase-1 and Phase-2 experiments: safely and effectively move multiple actuators individually or synchronously; sample and save effector control and position sensor feedback signals; automate control of actuator positioning based on a mode transition schedule; sample and save pressure sensor signals; and perform DAQ and control processes operating at 2.5 KHz. This document describes the hardware components used to build the SysID Rack including their function, specifications, and system interface. Furthermore, provided in this document are a SysID Rack effectors signal list (signal flow); system identification experiment setup; illustrations indicating a typical SysID Rack experiment; and a SysID Rack performance overview for Phase-1 and Phase-2 experiments. The SysID Rack described in this document was a useful tool to meet the project objectives. Thomas, Randy and Stueber, Thomas J. Glenn Research Center NASA/TM-2013-217864, E-18657 WBS 599489.02.07.03.07.11.02 SYSTEM IDENTIFICATION; REAL TIME OPERATION; HARDWARE-IN-THE-LOOP SIMULATION; ENGINE INLETS; DATA ACQUISITION; ACTUATORS; PRESSURE SENSORS; CONTROL EQUIPMENT; POSITIONING; FEEDBACK CONTROL; SUPERSONIC WIND TUNNELS


Best Sellers



Product Details
  • ISBN-13: 9798672023182
  • Publisher: Independently Published
  • Publisher Imprint: Independently Published
  • Height: 280 mm
  • No of Pages: 32
  • Spine Width: 2 mm
  • Width: 216 mm
  • ISBN-10: 8672023188
  • Publisher Date: 04 Aug 2020
  • Binding: Paperback
  • Language: English
  • Returnable: N
  • Weight: 100 gr
